- Описание
-
Описание:
7000-12221-2141000 | MURR ELEKTRONIK | Кабель
Технические характеристики и спецификация: 7000-12221-2141000
Connection lead; M12; PIN: 4; 10m; 4A; 7000; Colour: black
Датчики - Кабели
Наименование по производителю MURR ELEKTRONIK: 7000-12221-2141000
Производитель: MURR ELEKTRONIK .
Каталог: Полный каталог продукции MURR ELEKTRONIK .
Сроки поставки: 7-9 недель
Для уточнения точных сроков и цены, свяжитесь с нашими сотрудниками
Артикулы MURR ELEKTRONIK по каталогу и аналогом:
7000-12221-2141000
Cable length 10 m Page 1Tightening torque 0.6 Nm Fastening type plugged, screwed Coating Contact gold-plated Family design M12 thread M12 x 1 suitable for corrugated hose (inner diameter) 10 mm Cable outlet angled Coding A Material Contact copper alloy material PURE Number of poles 4 Wrench size SW13 Degree of protection (EN IEC 60529) IP65, IP66K, IP67 Page 2Stripping length 20 mm Family design open cable end Electrical data | SupplyOperating voltage DC 24 V Operating voltage DC min. 18 V Operating voltage DC max. 30 V Operating voltage DC max. (UL-listed) 30 V Operating current per contact max. 4 A DiagnosesStatus indicator LED yellow, green Installation | ConnectionStripping length 20 mm Fastening thread M12 x 1 Gender female Device protection | ElectricalDegree of protection (EN IEC 60529) IP65, IP67, IP66K Additional condition protection class plugged, screwed Degree of contamination 3 Rated impulse voltage 0.8 kV Insulating material group (IEC 60664-1) I Mechanical data | Material dataCoating locking matt nickel-plated Coating screw connection nickel-plated Locking material zinc die-casting Material screw connection zinc die-casting Mechanical data | Assembly dataFastening type plugged, screwed, vibration protection Environmental characteristics | ClimaticOperating temperature min. -30 °C Operating temperature max. 85 °C Additional condition temperature range depending on the connected line - Аксессуары и аналоги
-
