HT46CI/LP-M12 | Leuze Electronic | Датчик (арт. 50141258)
Технические характеристики: HT46CI/LP-M12
Производитель: Leuze Electronic
Обычные сроки поставки: 7-9 недель
Для уточнения точных сроков и цены, свяжитесь с нашими сотрудниками
Артикул по совпадению:
HT46CI/LP-M12
50141258
black-and-white error < 10% up to 1200 mm operating range guaranteed range Operating range, white 90% 0.005 ... 3 m operating range, gray 18% 0.02 ... 2 m operating range, black 6% 0.05 ... 1.5 m limit range 0.005 ... 3 m limit range typical range adjustment range 120 ... 3,000 mm beam path focused light source LED, infrared wavelength 860 nm LED group Free group (according to EN 62471) type of light spot geometry rectangular focus fix protective circuit Short-circuit protection
Transient protection
Reverse polarity protectionsupply voltage U B 10 ... 30 V, DC, including residual ripple residual ripple 0 ... 15 %, from U B no-load current 0 ... 30 mA number of digital switching outputs 2 pieces switching element transistor, push-pull switching principle IO-Link / light switching (PNP) / dark switching (NPN) switching element transistor, PNP switching principle dark switching switching frequency 250 Hz response time 2 ms standby delay 300 ms COM mode COM2 Min. cycle time COM2 = 2.3 ms specification V1.1 SIO mode support Yes function Signal OUT
power supplytype of connection round plug thread size M12 type male material plastic number of poles 4-pin coding A-coded Dimensions (W x H x L) 20.5 mm x 76.3 mm x 44 mm Housing material plastic plastic housing PC-PBT material optics cover plastic / PMMA net weight 60 g Color housing red type of fastening Through-hole fastening
via optional fastening partmaterial compatibility ECOLAB type of ad LED controls multi-speed spindle function of the control element sensing range adjustment ambient temperature operation -40 ... 60 °C ambient temperature storage -40 ... 70 °C protection class IP 67
IP 69K - Аксессуары и аналоги
-
